•Introduction:
1030/1038 series liquid pipeline filer drier protecting refrigeration and air conditioning system make it does not contain water. ocW and solid impurities-All drying rater core body is a molecutar sieve sintered filter, the core body is 100% of the 1030 series sintering filter, molecular sieve and 1038 series of moJecular sieve from 80%and 20% active aluminum sintering.
•Features:
1.Solid rater is a motecutar sieve portides stick together don’t move, avoid the powdef produced
2.1030 series and 1038 series have copper over braze welding interface and threaded connections are available
3.1030 series hove good drying and filtering abity. 1038 senes with odd absorption ond dry filtering capability
4.Filtration precision ot 25gm. can maintain effective fltefing in the minimum pressure drop
5.Surface coated with corrosion resistonl epoxy powder coating, match the requrement of 500 hours salt spray testing
6.Maximum working pressure of 45 bar
7.Applicable temperature -40℃-+120℃
|
Medium type |
1038 Series |
1030 Series |
|
|
Refrigerant |
HFC |
usable |
Suggested Use |
|
HCFC |
Suggested Use |
Usable |
|
|
CFC |
Suggested Use |
Not applicable |
|
|
Oil |
Mineral oil or AB |
Suggested Use |
Usable |
|
Pure POE or PAG |
Usable |
Suggested Use |
|
|
Additive POE or PAG |
Not applicable |
Suggested Use |
|
1030 series corresponding to Danfoss DML series, 1038 series corresponding to Danfoss DCL series For CFC system, it is recommended to use 1038 series dry filters, in these systems, may need to use with acid absorption can filter dryer For oil additive in the system, is not recommended to contain active aluminum filter dryer
|
Model |
Connedlons |
Pressure Drop △p （12） =0.07bar Fluid Refrigerating Capacity (Kw) |
（mm）Dimensions |
Type |
||||||||
| ODF | SAE | R134a | R22/R410A | R407C | R404A/507 | R502 | A | B | D | L | ||
|
1030/1038-032 |
1/4 |
6.7 |
5.1 |
4.9 |
7.5 |
7.1 |
22.5 |
66 |
43 |
111 |
FIGI |
|
|
I030/I038-032S |
1/4 |
6.7 |
5.1 |
4.9 |
7.5 |
7.1 |
16.5 |
99 |
FIG2 |
|||
|
1030/1038-033 |
3/8 |
12.9 |
9.9 |
9.6 |
14.5 |
13.8 |
27.5 |
121 |
FIG1 |
|||
|
1030/1038-033S |
3/8 |
12.9 |
9.9 |
9.6 |
14.5 |
13.8 |
19 |
104 |
FIG2 |
|||
|
1030/1038-052 |
1/4 |
7.7 |
5.6 |
5.5 |
8.5 |
8.0 |
22.5 |
75 |
54 |
120 |
FIG3 |
|
|
1030/10380S2S |
1/4 |
7.7 |
5.6 |
5.5 |
8.5 |
8.0 |
18.5 |
112 |
FIG4 |
|||
|
1030/1038-053 |
3/8 |
12.9 |
9.8 |
9.5 |
14.5 |
13.8 |
27.5 |
130 |
FIG3 |
|||
|
1030/1038-053S |
3/8 |
12.9 |
9.8 |
9.5 |
14.5 |
13.8 |
19 |
113 |
FIG4 |
|||
|
1030/1038-054 |
1/2 |
25.7 |
20.8 |
20.2 |
30.2 |
28.6 |
30 |
135 |
FIG3 |
|||
|
1030/1038-054S |
1/2 |
25.7 |
20.8 |
20.2 |
30.2 |
28.6 |
20 |
115 |
FIG4 |
|||
|
1030/1038-082 |
1/4 |
7.7 |
5.4 |
5.3 |
8.2 |
7.9 |
22.5 |
101 |
54 |
146 |
FIG5 |
|
|
1030/I038-082S |
1/4 |
7.7 |
5.4 |
S.3 |
8.2 |
7.9 |
18.5 |
136 |
FIG6 |
|||
|
1030/1038-083 |
3/8 |
14.2 |
11.0 |
10.7 |
16.2 |
15.3 |
27.5 |
156 |
FIG5 |
|||
|
1030/1038-083S |
3/8 |
14.2 |
11.0 |
10.7 |
16.2 |
15.3 |
19 |
139 |
FIG6 |
|||
|
1030/1038-084 |
1/2 |
28.6 |
21.4 |
20.7 |
31.7 |
30.2 |
30 |
161 |
FIGS |
|||
|
1030/1038-084S |
1/2 |
28.6 |
21.4 |
20.7 |
31.7 |
20.2 |
20 |
141 |
FIG6 |
|||
|
1030/1038-085 |
5/8 |
43.8 |
35.3 |
34.3 |
51.6 |
48.7 |
35 |
171 |
FIG5 |
|||
|
1030/1038 085S |
5/8 |
43.8 |
35.3 |
34.3 |
51.6 |
48.7 |
24 |
149 |
FIG6 |
|||
|
1030/1038-162 |
1/4 |
7.7 |
5.4 |
5.3 |
8.2 |
7.9 |
22.5 |
110 |
76 |
155 |
FIG5 |
|
|
1030/1038-162S |
1/4 |
7.7 |
5.4 |
5.3 |
8.2 |
7.9 |
18 |
146 |
FIG6 |
|||
|
1030/1038-163 |
3/8 |
16.3 |
11.2 |
10.8 |
16.8 |
16.2 |
27.5 |
165 |
FIG5 |
|||
|
1030/1038-163S |
3/8 |
16.3 |
11.2 |
10.8 |
16.8 |
16.2 |
19 |
148 |
FIG6 |
|||
|
1030/1038-164 |
1/2 |
32.2 |
23.5 |
22.7 |
35.1 |
33.6 |
30 |
170 |
FIG5 |
|||
|
1030/1038-164S |
1/2 |
32.2 |
23.5 |
22.7 |
35.1 |
33.6 |
20 |
150 |
FIG6 |
|||
|
1030/1038-165 |
5/8 |
44.6 |
36.6 |
35.6 |
53.4 |
50.2 |
35 |
180 |
FIG5 |
|||
|
1030/1038-166 |
3/4 |
44.5 |
37.4 |
36.4 |
54.4 |
51.2 |
40 |
190 |
FIG5 |
|||
|
1030/1038-166S |
3/4 |
44.5 |
37.4 |
36.4 |
54.4 |
51.2 |
26 |
162 |
HG6 |
|||
|
1030/1038-167S |
7/8 |
45.9 |
40.1 |
39.2 |
56.6 |
52.8 |
28.5 |
167 |
FIG6 |
|||
|
1030/1038-303 |
3/8 |
15.7 |
10.6 |
10.2 |
16.6 |
15.5 |
27.5 |
244 |
FIG7 |
|||
|
I030/1038-303S |
3/8 |
15.7 |
10.6 |
10.2 |
16.6 |
15.5 |
19 |
227 |
FIGS |
|||
|
1030/1038-304 |
1/2 |
32.5 |
25.0 |
24.3 |
36.8 |
35.1 |
30 |
249 |
FIG7 |
|||
|
1030/1038-304S |
1/2 |
32.5 |
25.0 |
24.3 |
36.8 |
35.1 |
20 |
229 |
FIG8 |
|||
|
1030/1038-305 |
5/8 |
43.7 |
36.9 |
35.9 |
53.8 |
50.9 |
35 |
189 |
76 |
259 |
FIG7 |
|
|
I030/I038-30SS |
5/8 |
43.7 |
36.9 |
35.9 |
53.8 |
50.9 |
24 |
237 |
FIG8 |
|||
|
1030/1038-306 |
3/4 |
45.7 |
39.8 |
38.9 |
55.6 |
52.5 |
40 |
269 |
FIG7 |
|||
|
1030/103a-306S |
3/4 |
45.7 |
39.8 |
38.9 |
55.6 |
52.5 |
26 |
241 |
FIG8 |
|||
|
1030/1038-307S |
7/8 |
64.3 |
54.0 |
52.5 |
77.8 |
73.3 |
28.5 |
246 |
FIG8 |
|||
|
I030/1038-309S |
1-1/8 |
83.6 |
69.8 |
67.9 |
101.6 |
95.0 |
29 |
247 |
FIG8 |
|||
|
1030/1038-413 |
3/8 |
18.4 |
12.4 |
12.0 |
19.2 |
18.2 |
27.5 |
246 |
FIG7 |
|||
|
1030/1038-414 |
1/2 |
33.4 |
26.5 |
25.7 |
38.6 |
36.7 |
30 |
251 |
FIG7 |
|||
|
1030/1038-4 US |
1/2 |
33.4 |
26.5 |
25.7 |
38.6 |
36.7 |
20 |
231 |
FIG8 |
|||
|
1030/1038-415 |
5/8 |
55.4 |
41.8 |
40.6 |
62.1 |
59.1 |
35 |
261 |
FIG7 |
|||
|
1030/1038-415S |
5/8 |
55.4 |
41.8 |
40.6 |
62.1 |
59.1 |
24 |
191 |
89 |
239 |
FIG8 |
|
|
1030/1038-416 |
3/4 |
62.4 |
53.8 |
52.6 |
76.6 |
72.4 |
40 |
271 |
FIG7 |
|||
|
1030/1038-416S |
3/4 |
62.4 |
53.8 |
52.6 |
76.6 |
72.4 |
26 |
243 |
FIG8 |
|||
|
1030/1038-417S |
7/8 |
66.7 |
56.3 |
54.8 |
80.2 |
76.3 |
28.5 |
248 |
FIG8 |
|||
|
1030/1038-419S |
1-1/8 |
95.3 |
76.3 |
74.1 |
112.3 |
105.4 |
29 |
249 |
FIG5 |
|||
Remark：1.capacity to work status: liquid refrigerant temperature te=30℃. saturated evaporation temperature=-15℃. the pressure drop △p=0.07bar
2.It is not recommended used when pressure drop △p over than 0.14 bar.
